Heat fixing 3 colors different stone automatic ultrasonic hot fix rhinestone machine

FOB Reference Price:Get Latest Price
US $6,950-11,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Fabric
Automatic Grade:
Automatic
Production Capacity:
3 colors different rhinestone in one time
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Disen
Model Number:
DS-DZJ03C
Voltage:
220V/110V
Power(W):
2600W
Dimension(L*W*H):
2400mmX1200mmX1200mm
Weight:
300kg
Features:
Multifunction
Certification:
CE Certification
Product name:
hot fix rhinestone machine
Function:
Hot Fix Rhinestones Applicator
Commodity name:
rhinestone machine
Item:
ultrasonic hot fix rhinestone machine
Air Pressure:
0.5 MPa
Working area:
300mmX500mm Optional
Net Size:
According to machine types
Size of Rhinestone:
2mm-7.5mm Optional
Keyword:
hot fix stone fixing machine
Name:
hot fix rhinestone machine
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plywood case,Heat fixing 3 colors different stone automatic ultrasonic hot fix rhinestone machine
Port
Guangzhou,Shenzhen,Hongkong
Lead Time :
one week

Detailed Images



1,This equipment can finish 3 colors different rhinestone in one time with stick on the fabric.
2,New technology can make sure all the colors match exactly.
3,Stick paper as a consumables in equipment can match the maximum value of use.



Working power supplyAC220V  50/60Hz
 Working pressure0.5 MPa
Working area 300mmX500mm Optional
 Power consumption5W Static/2600W Dynamic
 Size of Rhinestone2mm-7.5mm  Optional
 Overall dimensions2400mmX1200mmX1200mm
 Weight300Kg
Product Effects











Ultrasonic drilling machine ultrasonic bead machine ultrasonic point drilling machine
Ultrasonic hot drilling machine
principle:
Ultrasonic hot drilling, Dingzhu, point drill, is the use of ultrasonic high-frequency sound generator to produce 20KHZ (or 15KHZ) high-pressure, high-frequency signal, through the transducer system, the signal is converted to high-frequency mechanical vibration, (Bead), the temperature of the interface to the interface is increased by the friction between the drilling surface and the inner molecular member, and the diamond (bead) interface is rapidly melted when the temperature reaches the melting point of the diamond (beads) itself, Heat fixing 3 colors different stone automatic ultrasonic hot fix rhinestone machine,And then filled in the gap between the interface, when the vibration stops, diamonds (beads) at the same time under certain pressure cooling stereotypes, to achieve a perfect welding.
Traditional leather hot drilling is the use of heating plate heating method to make diamonds and glue melting to achieve the purpose, but this method is easy to make leather deformation, yellow, Heat fixing 3 colors different stone automatic ultrasonic hot fix rhinestone machine,loss of gloss, diamonds easy to fall off the use of ultrasonic hot drilling machine these problems can be solved.



Automatic ultrasonic drilling machine
1. The machine can be instantly fixed to the material (velvet, denim, knitted fabric, P leather, New Year film and other synthetic leather) by ultrasonic wave.

2. Apply to footwear hot drilling, underwear, children's clothing, Embroidery patterns, leather, handbags, hair accessories, hats and other jewelry;

3. The machine can play three different colors and different specifications of the diamond, improve production efficiency

4. Infrared positioning, hot drilling positioning accuracy, and very strong; Heat fixing 3 colors different stone automatic ultrasonic hot fix rhinestone machine,The characteristics of the machine through the instantaneous wave of ultrasonic drilling, can be reduced to a large extent artificial, a machine can reach dozens of work efficiency.
